2-4. Wall mounted type
Model name ASYG07LUCA ASYG09LUCA ASYG12LUCA ASYG14LUCA
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 13 16 19 23
Running current A 0.13 0.14 0.17 0.20
Fan
Airflow rate
Cooling
HIGH
m
3
/h
570 600 660 710
MED 520 550 600 640
LOW 470 470 530 570
QUIET 330 330 330 390
Heating
HIGH 570 600 660 710
MED 520 550 600 640
LOW 470 470 530 590
QUIET 330 330 330 430
Type × Q'ty Cross flow fan × 1
Motor output W 36
Sound pressure level *
Cooling
HIGH
dB (A)
35 36 37 41
MED 30 32 34 36
LOW 28 28 31 33
QUIET 21 21 21 25
Heating
HIGH 35 36 37 41
MED 30 32 34 36
LOW 28 28 31 34
QUIET 21 21 21 27
Sound power level
Cooling
dB (A)
53 54 55 59
Heating 53 54 55 59
Heat exchanger type
Dimensions (H × W × D) mm
Main: 320 × 690 × 20
Sub: 84 × 690 × 13.3
Fin pitch mm Main: 1.1, Sub: 1.4
Rows × Stages Main: 2 × 20, Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
(Approximate color of Munsell N 9.3)
Dimensions
(H × W × D)
Net
mm
282 × 870 × 185
Gross 247 × 920 × 373
Weight
Net
kg
9.5
Gross 12
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8) Ø12.7 (Ø1/2)
Method Flare
Drain hose
Material PP + LLDPE
Size mm Ø13.8 (I.D.), Ø15.8 to Ø16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 15 -
