2. Specifications
2-1. Compact cassette type
Model name AUYG07LVLA AUYG09LVLA AUYG12LVLB
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5
Input power W 18 23
Running current A 0.15 0.19
Fan
Airflow rate
Cooling
HIGH
m
3
/h
540 610
MED 490 530
LOW 440 470
QUIET 390 410
Heating
HIGH 540 610
MED 490 530
LOW 440 470
QUIET 390 410
Type × Q'ty Turbo fan × 1
Motor output W 54
Sound pressure level *
Cooling
HIGH
dB (A)
33 37
MED 31 33
LOW 29 31
QUIET 27 28
Heating
HIGH 34 37
MED 32 33
LOW 29 31
QUIET 27 28
Sound power level
Cooling
dB (A)
46 49
Heating 47 49
Heat exchanger type
Dimensions (H × W × D) mm 210 × 1,310 × 13.3 + 210 × 1,250 × 13.3
Fin pitch mm 1.2
Rows × Stages 2 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
245 × 570 × 570
Gross 265 × 730 × 625
Weight
Net
kg
15
Gross 18
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Drain hose
Material Hard PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Cassette grille
Model name UTG-UFYD-W
Material PS
Color
White
(Approximate color of Munsell N 9.25/)
Dimensions
(H × W × D)
Net
mm
49 × 700 × 700
Gross 120 × 765 × 755
Weight
Net
kg
2.6
Gross 4.5
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
