2-6. Floor type
Model name AGYG09LVCA AGYG12LVCA AGYG14LVCA
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 2.5 3.5 4.0
Input power W 16 20 23
Running current A 0.15 0.18 0.20
Fan
Airflow rate
Cooling
HIGH
m
3
/h
530 600 650
MED 440 490 520
LOW 360 380 400
QUIET 270 270 270
Heating
HIGH 530 600 650
MED 460 510 540
LOW 380 410 430
QUIET 270 270 270
Type × Q'ty Cross flow fan × 2
Motor output W 16
Sound pressure level *
Cooling
HIGH
dB (A)
39 42 44
MED 34 36 38
LOW 28 30 31
QUIET 22 22 22
Heating
HIGH 39 42 44
MED 35 38 39
LOW 30 32 33
QUIET 22 22 22
Sound power level
Cooling
dB (A)
52 55 56
Heating 52 55 56
Heat exchanger type
Dimensions (H × W × D) mm 378 × 550 × 26.6
Fin pitch mm 1.2
Rows × Stages 2 × 18
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
(Approximate color of Munsell N 9.25/)
Dimensions
(H × W × D)
Net
mm
600 × 740 × 200
Gross 700 × 820 × 310
Weight
Net
kg
14
Gross 17
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8) Ø12.70 (Ø1/2)
Method Flare
Drain hose
Material PVC
Size mm Ø13.8 (I.D.), Ø16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
