5-4. Wall mounted type
¢
Models: ASYG07LUCA and ASYG09LUCA
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2
1
0
1
2
(m)
(m)
01234567
8
Unit: m/s
0.751.0
0.5
0.25
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
Unit: m/s
(m)
0 12345678
(m)
0
1
1
2
2
3
3
0.75
0.5
0.25
0.75
1.0
1.0
0.5
0.25
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
012345678
0.75
1.0
0.5
0.25
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
012345678
0.75
1.0
0.5
0.25
