Fujitsu ASYG12LMCA Design & Technical Manual

11. External input and output
11-1. Compact cassette, slim duct, wall mounted, floor/ceiling,
and floor types
Indoor unit
type
External input External output
Control input
Operation
status output
Fresh air
control output
Auxiliary
heater output
Error status
output
Compact
cassette
● ● ● ― ―
Slim duct ● ● ● ● ―
Wall mounted ● ● ― ―
●
(LU/LM types)
Floor/Ceiling ● ● ― ― ―
Floor ● ● ― ― ―
¢
External input
With using external input function, some functions on this product can be controlled from an exter-
nal device.
• “Operation/Stop” mode or "Forced stop" mode can be selected with function setting of indoor
unit.
• A twisted pair cable (22AWG) should be used. Maximum length of cable is 150 m.
• The wire connection should be separate from the power cable line.

Control input (Operation/Stop or Forced stop)
Indoor unit type Connector
Compact cassette
CN102
Slim duct
Wall mounted
LU/LM CNA01
LF CN14
Floor/Ceiling CN102
Floor CN14
The air conditioner can be remotely operated by means of the following on-site work.
Operation is started at the following contents by adding the contact input of a commercial on/off
switch to a connector on the external control PCB and turning it on.
Unit operation Initial setting after power is on
Starting mode other than initial
setting
Operation mode Auto changeover Mode at previous operation
Set temperature 24 °C Temperature at previous operation
Airflow mode AUTO Mode at previous operation
Air direction (swing) Standard air direction (swing: off) Air direction at previous operation
DESIGN & TECHNICAL MANUAL
- 138 -
MULTI TYPE 5, 6 ROOMS TYPE
