1. Specifications
Type Inverter heat pump
Model name AOYG36LBLA5
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Standard combination of indoor unit
Wall mounted
ASYG07LMCA × 4
ASYG09LMCA × 1
Capacity
Cooling
Rated
kW 10.0
Btu/h 34,100
Min.—Max.
kW 3.5—12.5
Btu/h 11,900—42,700
Heating
Rated
kW 12.0
Btu/h 41,000
Min.—Max.
kW 3.5—14.0
Btu/h 11,900—47,800
Input power
Cooling
Rated
kW
2.44
Max. 4.04
Heating
Rated 2.79
Max. 3.98
Current
Cooling
Rated
A
10.6
Max. 20.6
Heating
Rated 12.3
Max. 20.6
EER Cooling
kW/kW
4.10
COP Heating 4.30
Starting current A 12.3
Maximum operating current *
1
A 20.6
Fan
Airflow rate
Cooling
m
3
/h
4,200
Heating
Type × Q'ty Propeller × 1
Motor output W 111
Sound pressure level*
2
Cooling
dB (A)
53
Heating 55
Heat exchanger type
Dimensions
(H × W × D)
mm
966 × 922 × 55
Fin pitch 1.45
Rows × Stages 3 ×46
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty DC twin rotary × 1
Motor output W 2,100
Refrigerant
Type (Global warming potential) R410A (2088)
Charge g 4,000
Refrigerant oil
Type RB68
Amount
cm
3
1,150
Enclosure
Material Steel sheet
Color
Beige
(Approximate color of Munsell 10YR 7.5/1.0 NN)
Dimensions
(H × W × D)
Net
mm
998 × 970 × 370
Gross 1,162 × 1,150 × 478
Weight
Net
kg
94
Gross 104
Connection pipe
Size
Liquid
mm
Ø 6.35 (Ø 1/4) x 5
Gas Ø 9.52 (Ø3/8) x 3 + Ø 12.70 (Ø 1/2) x 2
Method Flare
Pre-charge length (Total)
m
50
Maximum length (Total) 80
Maximum length (Each) 25
Minimum length (Total) 15
Minimum length (Each) 5
Maximum height difference between out-
door unit and each indoor units.
15
Maximum height difference between in-
door units.
10
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
NOTES:
• Specifications are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
• *1: The maximum current is the maximum value when the operated within the operation range.
• *2: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Connect to connection valve by the adapter.
• For other combination, refer to the combination table.
• The protective function might work when using it outside the operation range.
DESIGN & TECHNICAL MANUAL
- 274 -
OUTDOOR UNIT
AOYG36LBLA5
