Model name ARYG14LSLAP ARYG18LSLAP
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 4.0 5.0
Input power Fan
HIGH
W
72 63
MED 44 38
LOW 30 22
QUIET 18 19
Running current A 0.58 0.49
Fan
Airflow rate
Cooling
HIGH
m
3
/h
800 940
MED 640 750
LOW 530 540
QUIET 360 480
Heating
HIGH 800 940
MED 640 750
LOW 530 540
QUIET 360 480
Type × Q'ty Sirocco fan × 2 Sirocco fan × 3
Motor output W 75 80
Recommended static pressure Pa 0 to 50
Sound pressure level *
Cooling
HIGH
dB (A)
35 33
MED 30 29
LOW 27 26
QUIET 23 23
Heating
HIGH 35 33
MED 30 29
LOW 27 26
QUIET 23 23
Sound power level
Cooling
dB (A)
60 58
Heating 62 59
Heat exchanger type
Dimensions (H × W × D) mm 336 × 490 × 26.6 336 × 690 × 26.6
Fin pitch mm 1.3
Rows × Stages 2 × 16
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Steel sheet
Color —
Dimensions
(H × W × D)
Net
mm
198 × 700 × 450 198 × 900 × 450
Gross 250 × 930 × 580 250 × 1,130 × 580
Weight
Net
kg
15.5 18.5
Gross 19.5 23.0
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.7 (Ø1/2)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Drain hose
Material Hard PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Remote controller type Wired (Wireless [option])
NOTES:
• Values mentioned in the table are based on the following conditions:
– Static pressure: 15 Pa
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 12 -
MULTI TYPE
5, 6 ROOMS TYPE
