Parts

Wireless remote controller

AR-RAH2E AR-RAH1E AR-REA2E AR-REB1E

Wired remote controller

UTY-RNNYM UTY-RVNYM UTY-RLRY UTY-RNRYZ*

IR receiver kit with Wireless remote

controller

Simple remote controller

UTY-LRHYM UTY-LBTYM UTY-RSNYM UTY-RSRY UTY-RHRY

DESIGN & TECHNICAL MANUAL

- 264 -

MULTI TYPE

5, 6 ROOMS TYPE

Default Chapter1
- Air Conditioner1
- Table of Contents3
Part 1. INDOOR UNIT9
- Model Lineup10
  - Connectable Indoor Units to each Outdoor Unit11
  - Indoor Unit Connection Patterns12
- Specifications17
- Dimensions29
- Wiring Diagrams49
- Air Velocity and Temperature Distributions57
- Fan Performance98
  - Mini Duct Type98
  - Slim Duct Type108
- Airflow110
- 8 Noise Level Curve124
- Electrical Characteristics144
Safety Devices145
External Input and Output146
- 11-1.Compact Cassette, Slim Duct, Wall Mounted, Floor/Ceiling, and Floor Types146
- 11-2.Mini Duct Type156
Group Connection162
- 12-1.Precautions on Creating a Group Connection163
Part 3. OUTDOOR UNIT (6 ROOMS TYPE)163
- 12-2.Remote Controller Address Setting Procedure for Wireless Remote Controllers165
Remote Controller166
- 13-1.Wireless Remote Controller (AR-RAH2E/AR-RAH1E)166
- Sleep Button167
- Specifications168
- 13-2.Wireless Remote Controller (AR-REA2E/AR-REB1E)169
- 13-3.IR Receiver Kit with Wireless Remote Controller (UTY-LRHYM: Optional Part)172
- 13-4.IR Receiver Kit with Wireless Remote Controller (UTY-LBTYM: Optional Part)175
- 13-5.Wired Remote Controller (UTY-RNNYM)178
- 13-6.Wired Remote Controller (UTY-RLRY)183
- 13-7.Wired Remote Controller (UTY-RVNYM: Optional Part)186
- 13-8.Wired Remote Controller (UTY-RNRYZ*: Optional Part)195
- 13-9.Simple Remote Controller (UTY-RSNYM: Optional Part)198
- 13-10.Simple Remote Controller (UTY-RSRY and UTY-RHRY: Optional Parts)203
- Status Icons203
Function Settings206
- 14-1.Compact Cassette, Slim Duct, and Floor/Ceiling Types Indoor Unit (Setting by DIP Switch and Jumper Wire)206
- 14-2.Mini Duct Type Indoor Unit (Setting by DIP Switch)208
- 14-3.Indoor Unit (Setting by Wireless Remote Controller)210
- 14-4.Indoor Unit (Setting by Wired Remote Controller)231
- 14-5.Indoor Unit (Setting by Simple Remote Controller)242
- 14-6.Function Details249
- 14-7.Wired Remote Controller (UTY-RNNYM)257
- 14-8.Wired Remote Controller (UTY-RVNYM)259
- 14-9.Wired Remote Controller (UTY-RLRY)260
- 14-10.Wired Remote Controller (UTY-RNRYZ*)261
- 14-11.Simple Remote Controller (UTY-RSNYM)262
Accessories263
- 15-1.Compact Cassette Type263
- Cassette Grille273
- Others274
Indoor Unit Installation Precautions278
- Points to Remember When Installing279
Part 2. OUTDOOR UNIT (5 ROOMS TYPE)281
- Specifications282
- Dimensions284
  - Model: AOYG36LBLA5284
- Installation Space285
  - Model: AOYG36LBLA5285
- Refrigerant Circuit288
  - Model: AOYG36LBLA5288
- Wiring Diagram289
  - Model: AOYG36LBLA5289
- Capacity Table290
- Capacity Compensation Rate for Pipe Length and Height Difference324
  - Model: AOYG36LBLA5324
- Additional Charge Calculation328
  - Model: AOYG36LBLA5328
- Airflow329
  - Model: AOYG36LBLA5329
Operation Noise (Sound Pressure)330
- 10-1.Noise Level Curve330
- 10-2.Sound Level Check Point330
Electrical Characteristics331
Safety Devices332
Function Settings333
- 13-1.Setting Methods333
Check and Test337
- 14-1.Check Run337
- 14-2.Test Run343
- 14-3.Error Code344
  - 14-3.Error Code345
  - 14-4.Pump down347
Accessories349
Optional Parts350
Outdoor Unit Installation Precautions351
- 17-1.Place Where Prohibited for Use351
- 17-2.Points to Remember When Installing351
Optional Parts424
- Outdoor Unit Installation Precautions425
