Mini duct type
MODEL: ARYG07LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.06 1.96 1.88 1.84 1.80
-10.0 -11.0 2.30 2.19 2.12 2.08 2.03
-5.0 -7.0 2.56 2.45 2.36 2.32 2.29
0.0 -2.0 2.82 2.71 2.60 2.54 2.47
5.0 3.0 3.17 3.02 2.80 2.71 2.61
7.0 6.0 3.24 3.05 2.80 2.67 2.54
10.0 8.0 3.21 3.02 2.80 2.67 2.54
15.0 10.0 3.21 3.00 2.80 2.68 2.56
20.0 15.0 3.19 2.98 2.80 2.69 2.58
24.0 18.0 3.15 2.96 2.80 2.75 2.70
MODEL: ARYG09LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.64 2.52 2.42 2.37 2.32
-10.0 -11.0 2.96 2.82 2.73 2.67 2.61
-5.0 -7.0 3.29 3.15 3.03 2.99 2.94
0.0 -2.0 3.62 3.48 3.34 3.26 3.18
5.0 3.0 4.08 3.89 3.60 3.48 3.36
7.0 6.0 4.16 3.92 3.60 3.43 3.26
10.0 8.0 4.13 3.89 3.60 3.43 3.27
15.0 10.0 4.13 3.86 3.60 3.45 3.29
20.0 15.0 4.10 3.84 3.60 3.46 3.32
24.0 18.0 4.04 3.81 3.60 3.54 3.47
MODEL: ARYG12LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.53 3.36 3.22 3.16 3.09
-10.0 -11.0 3.94 3.76 3.63 3.56 3.48
-5.0 -7.0 4.38 4.20 4.05 3.98 3.92
0.0 -2.0 4.83 4.64 4.46 4.35 4.24
5.0 3.0 5.44 5.18 4.80 4.64 4.48
7.0 6.0 5.55 5.22 4.80 4.58 4.35
10.0 8.0 5.51 5.19 4.80 4.58 4.36
15.0 10.0 5.50 5.15 4.80 4.60 4.39
20.0 15.0 5.46 5.12 4.80 4.61 4.43
24.0 18.0 5.39 5.08 4.80 4.72 4.63
MODEL: ARYG14LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.11 3.92 3.76 3.68 3.60
-10.0 -11.0 4.60 4.38 4.24 4.15 4.06
-5.0 -7.0 5.11 4.90 4.72 4.65 4.58
0.0 -2.0 5.63 5.42 5.20 5.07 4.95
5.0 3.0 6.35 6.05 5.60 5.41 5.23
7.0 6.0 6.48 6.09 5.60 5.34 5.08
10.0 8.0 6.43 6.05 5.60 5.34 5.08
15.0 10.0 6.42 6.01 5.60 5.36 5.12
20.0 15.0 6.37 5.97 5.60 5.38 5.16
24.0 18.0 6.29 5.93 5.60 5.50 5.40
MODEL: ARYG18LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 5.29 5.04 4.83 4.73 4.63
-10.0 -11.0 5.91 5.64 5.45 5.34 5.22
-5.0 -7.0 6.57 6.30 6.07 5.98 5.89
0.0 -2.0 7.24 6.96 6.69 6.52 6.36
5.0 3.0 8.16 7.78 7.20 6.96 6.72
7.0 6.0 8.33 7.83 7.20 6.86 6.53
10.0 8.0 8.27 7.78 7.20 6.87 6.53
15.0 10.0 8.25 7.73 7.20 6.89 6.59
20.0 15.0 8.19 7.67 7.20 6.92 6.64
24.0 18.0 8.09 7.62 7.20 7.07 6.95
DESIGN & TECHNICAL MANUAL
- 308 -
