Fujitsu ASYG12LMCA Design & Technical Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
49
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
48
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
47
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
46
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
45
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
44
-10.0
10.98 1.77 12.40 1.80 13.08 1.81 14.00 1.83 14.97 1.86 15.43 1.87
-5.0 10.98 1.76 12.40 1.79 13.08 1.80 14.00 1.82 14.97 1.85 15.43 1.86
0.0 10.98 1.75 12.40 1.78 13.08 1.79 14.00 1.81 14.97 1.84 15.43 1.85
5.0 10.98 1.95 12.40 1.98 13.08 2.00 14.00 2.02 14.97 2.04 15.43 2.06
10.0 10.98 2.15 12.40 2.19 13.08 2.20 14.00 2.23 14.97 2.25 15.43 2.27
15.0 10.98 2.96 12.40 3.01 13.08 3.03 14.00 3.07 14.97 3.10 15.43 3.12
20.0 10.98 3.77 12.40 3.83 13.08 3.86 14.00 3.91 14.97 3.95 15.43 3.97
25.0 10.98 4.15 12.40 4.22 13.08 4.26 14.00 4.30 14.97 4.35 15.43 4.38
30.0 10.98 4.53 12.40 4.61 13.08 4.65 14.00 4.70 14.97 4.76 15.43 4.78
35.0 10.98 4.84 12.40 4.92 13.08 4.96 14.00 5.02 14.97 5.08 15.43 5.11
40.0 9.55 4.49 10.79 4.57 11.37 4.61 12.18 4.66 13.02 4.71 13.42 4.74
46.0 8.12 4.15 9.18 4.22 9.67 4.25 10.36 4.30 11.07 4.35 11.41 4.37
43
-10.0
10.73 1.70 12.12 1.73 12.78 1.74 13.68 1.76 14.63 1.78 15.08 1.79
-5.0 10.73 1.69 12.12 1.72 12.78 1.74 13.68 1.75 14.63 1.77 15.08 1.78
0.0 10.73 1.68 12.12 1.71 12.78 1.73 13.68 1.75 14.63 1.77 15.08 1.77
5.0 10.73 1.87 12.12 1.91 12.78 1.92 13.68 1.94 14.63 1.97 15.08 1.98
10.0 10.73 2.07 12.12 2.10 12.78 2.12 13.68 2.14 14.63 2.17 15.08 2.18
15.0 10.73 2.84 12.12 2.89 12.78 2.92 13.68 2.95 14.63 2.98 15.08 3.00
20.0 10.73 3.62 12.12 3.69 12.78 3.72 13.68 3.76 14.63 3.80 15.08 3.82
25.0 10.73 3.99 12.12 4.06 12.78 4.09 13.68 4.14 14.63 4.19 15.08 4.21
30.0 10.73 4.36 12.12 4.44 12.78 4.47 13.68 4.52 14.63 4.58 15.08 4.60
35.0 10.73 4.66 12.12 4.74 12.78 4.78 13.68 4.83 14.63 4.88 15.08 4.91
40.0 9.33 4.32 10.54 4.40 11.12 4.43 11.90 4.48 12.72 4.53 13.12 4.56
46.0 7.93 3.99 8.97 4.06 9.45 4.09 10.12 4.14 10.82 4.19 11.15 4.21
- 363 -
OUTDOOR UNIT AOYG45LBLA6
