Fujitsu ASYG12LMCA Design & Technical Manual

MODEL: ARYG18LLTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
-5.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
0.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
5.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
10.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
15.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
20.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
25.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
30.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
35.0 3.75 2.30 4.51 2.81 5.09 3.20 5.75 4.14 6.15 4.53 6.34 5.19
40.0 3.26 1.74 3.92 2.12 4.43 2.42 5.00 3.13 5.35 3.43 5.51 3.93
46.0 2.77 1.26 3.33 1.54 3.77 1.75 4.25 2.27 4.55 2.48 4.69 2.84
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 371 -
OUTDOOR UNIT AOYG45LBLA6
