Installation space requirement
Provide sufficient installation space for product safety.
Unit: mm
45 or more
1,800 or more
63 or more
Outline of unit
25 or more
52 or more
144 or more
1,500 or more
86 or more
- 33 -
MULTI TYPE
5, 6 ROOMS TYPE
