Installation space
Left Right
300 or more 300 or more
Ceiling
Left
Indoor unit
Right
150 or more 300 or more
Ceiling
20 or more
1,000 or more
2,300 or more
Obstruction
Floor
Unit: mm
- 39 -
MULTI TYPE
5, 6 ROOMS TYPE
