Fujitsu ASYG12LMCA Design & Technical Manual

• Air velocity distribution
Measuring conditions
Fan speed Operation mode
HIGH HEAT
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2
1
0
(m)
Unit: m/s
(m)
0
12 345678910
2.5
3
2
1
0.5
• Air temperature distribution
Measuring conditions
Fan speed Operation mode
HIGH HEAT
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2
1
0
(m)
Unit: °C
(m)
01 2 3 4 5 6 78 9
2.5
3
10
30
28
26
24
22
DESIGN & TECHNICAL MANUAL
- 68 -
MULTI TYPE 5, 6 ROOMS TYPE
