Getting s tarted
Connecting the device
Please observe the safety information in "Import ant notes", Page 7.
CE conformance and optimum pict ure quality are guaranteed only if
you use the data cables supplied.
► Switch off the monitor an d the computer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The data cab les s upplie
d have two 1 5-pin D-SUB connectors or two 24-pin DVI
connectors for connect
ion to the monitor and to the computer.
Information on the co m
puter connections and interfaces is contained in the
operating manua l for
the computer.
469
2
58
73
9
1
1=Securi
ty slot for Security Lock
2 = Power connector
3=AUDIO
-IN socket
4 = DisplayPort socket
5=DVI-D
socket (DVI)
6=D-SUBs
ocket (VGA)
7 = AUDIO-OUT socket
8=USBIN
(Upstream)
9 = USB O UT (Downstream)
► Select th e appropriate data cable for your computer.
16 Fujitsu
