Features System overview
26 U41858-J-Z126-2-76
SE700 and SE500
The figure below shows how the basic rack of the SE700 is equipped with the components
of the basic configuration and with optional components. The equipment is comparable for
the SE500.
Figure 3: System components SE700 and SE700B
SE700 - Basic configuration SE700 with optional components
CHE box #0
CHE box #1
HNC (2)
MU (MU1)
SU700
Service drawer
Rack console
Net Unit (1)
Net Unit (2)
CHE box #4
HNC (1)
CHE box #5
CHE box #2
CHE box #6
CHE box #3
CHE box #7
(FUJI-C9 CPU box)
