6.2 Rear of the MU
Figure 13: Management Unit (MU) - rear of a MU M1
Figure 14: Management Unit (MU) - rear of a MU M2
The figure 13 and figure 14 show the rear of a MU M1 and MU M2 with PCIe slots which
are not equipped.
ID/CSS/Global error indicator
Figure 15: ID/CSS/Global error indicator (MU M1)
