Rear of the MU Management Unit
56 U41858-J-Z126-2-76
Bild 16: ID/CSS/Global error indicator (MU M2)
1 ID/CSS/Global error indicator
ID ID indicator (blue)
Lights up blue when the MU has been selected by pressing the ID button. To
deactivate, press the button again.
The ID indicator can also be activated via the ServerView Operations
Manager and the iRMCS4 web interface, and the status can be reported to the
ServerView Operations Manager and the iRMCS4.
CSS CSS and Global error indicator (yellow/orange)
Generally, the states of these indicators have the following meanings:
– Do not light up when the MU is OK.
– If the event is still acute after a power failure, the indicator is activated after
the restart.
– Light up when a prefailure event was detected. The indicator also lights
up in standby mode.
– Flash when an error was detected. The indicator also flashes in standby
mode.
Irrespective of the color, when an indicator lights up or flashes this indicates
an error event. Please notify customer support.
