Control panel (on the SE700 and SE500) Controls
46 U41858-J-Z126-2-76
5.3.1 Function of the displays
POWER ON
Lights up green after the system power controller has completed the power-up
sequence without error. In the standby status the indicator flashes.
SYSTEM
Lights up green when the CPU(s) is/are in operation.
CHECK
Lights up red when the SVP has detected a hardware malfunction or a fault in the power
supply of the SU /390. In the event of a fault a buzzer sounds at the same time.
STATUS indicator
Depending on the POWER ON indicator, this indicator is switched on and displays details
of the hardware status with a three-character alphanumeric display.
The display changes as sequences are executed. If the display finally stops at a particular value not
equal to "000", this must be interpreted as the error code for a problem. In this case Customer Support
should be contacted.
POWER ON STATUS indicator Hardware status
Does not light
up
Does not light up Power failure
Does not light
up
b00 through bFF Power supply units are being initialized.
Flashing Does not light up (in maintenance mode
CE0)
Standby mode
Lights up 001 through 010 Power-on sequence is active.
Lights up 100 through 399 System is being initialized.
Lights up 000 System initialization completed.
Lights up 500 through 599 System stop initiated.
Lights up 010 through 001 Power-off sequence is active.
Lights up or
does not light
up (depending
on the
STATUS)
Begins with A The entire /390 system (CPU box,
AROMA, CHE boxes) or parts of it have
been switched off because of a fault
(power supply or operating temperature).
Or an important function of the SVP has
been stopped and a detailed error code
cannot be displayed on the SVP console.
Lights up EEE Another error has occurred. A detailed
error code is displayed on the SVP
console.
Table 1: STATUS indicator
