3.1.1 Rack of the SE server
SE300
The figure below shows how the basic rack of the SE300 is equipped with the components
of the basic configuration and with optional components.
Figure 2: System components SE300 and SE300B
SE300 - Basic configuration SE300 with optional components
SU300 (SU1)
SU300 (SU2)
AU47 (AU1)
AU47 (AU2)
MU (MU1)
MU (MU2)
DX500 S3 DS
DX500 S3 DS
DX500 S3 contr.
Service drawer
Rack console
Net Unit (1)
Net Unit (2)
