Indicators on the operating panel

Optical drive activity indicator

Lights up green when the storage medium is accessed. See also figure 10 on page 50 and

figure 11 on page 51.

Power-on indicator (three colors)

Lights up orange

when the MU is switched off but line voltage is present. After

the power cables have been connected, it takes about 60 seconds until the

MU is in standby mode.

Lights up yellow during power up delay.

I If the MU is switched off and then immediately switched on again, iis

only restarted after a power up delay. This prevents a current

overload, for example.

Lights up green when the MU is switched on.

Flashes green when the MU has been switched on and is in standby mode or

in sleep mode.

Hard disk activity indicator (green)

Flashes green when an internal hard disk drive is being accessed.

CSS CSS and Global error indicators (yellow/orange)

Generally, the states of these indicators have the following meanings:

– Do not light up when the MU is OK.

– If the event is still acute after a power failure, the indicator is activated

after the restart.

– Light up when a prefailure event was detected. The indicator also lights

up in standby mode.

– Flash when an error was detected. The indicator also flashes in standby

mode.

Irrespective of the color, when an indicator lights up or flashes this indicates

an error event. Please notify Customer Support when this happens.

ID ID indicator (blue)

Lights up blue when MU has been selected by pressing the ID button. To

deactivate, press the button again.
