102
Modular
RAID
Controllers
Modular RAID 12Gb/s (SAS3.0)
5.5.2
Controller versions
I
The following TFM k
it is available.
Figure 37: "PRAID E
P420e" with installed TFM
Name
Chip
PCIe
No. of SAS
channels
Bracket
type
PRAID EP420e
LSI SAS3108
PCIe 3.0
8
low profile
full height
Name
Cache
TFM kit
PRAID EP420e
2
GB
PRAID EP420i TFM (LSZ:03-25444-01)
1
Connector for FBU adapter cable
101
103
