Fujitsu D2616 User Manual

50 Modular RAID Controllers
Modular RAID 6Gb/s (SAS2.0)
Connectors
Indicators
4.3.4 Installation
This section describes how to install the SAS RAID controller in a server.
V CAUTION!
To safeguard against data loss, remember to back up your data before
you change your system configuration.
To install the new controller, proceed as follows:
Connector Type Description
SAS0 x1 SAS0 SATA connectors to connect local
SAS/SATA hard disk drives
SAS1 x1 SAS1 SATA connectors to connect local
SAS/SATA hard disk drives
SDB SAS side band
signals
6-pin connector
SAS side band connector
BBU Connector for direct iBBU connection
LED Description
HB Heart Beat
WP Write in cache pending
WA Warning
Step 1 Unpack the controller
Unpack the new controller in a static-free environment. Remove
it from the anti-static bag and inspect it for damage.
If the controller appears to be damaged, contact the Fujitsu
support service.
Step 2 Prepare the server
Shut down and power off the server and remove the server blade
from the chassis.
