Fujitsu D2616 User Manual

Modular RAID Controllers 71
Modular RAID 6Gb/s (SAS2.0)
4.6.1 Features
● Flexibility for both SAS 2.0 and SATA II / SATA III
● Advanced management and configuration suites
● 12V PCIe RAID HDD module
● Supports RAID levels 0, 1, 1E, 10
● Offers advanced MegaRAID functionality to integrated LSI SAS
● 8-lane 5.0 / 8.0 Gbit PCIe host bus
● 6 SAS/SATA ports, (2+2 ports for Storage Blade Connection and 2 ports for
Blade internal HDD Connection)
● Each SAS/SATA port supports SSP and STP
● Support for the following STP features:
– Addressing of SATA targets through expander
– Native Command Queuing (NCQ)
● Support of the following SSP features:
– Wide port functionality (2x2 Phys from a single quad port)
– Narrow port functionality (1 Phy)
– Compatible with SATA target devices
● SGPIO interfaces for signaling of SAS/SATA ports
● Drive spin-up sequencing control
● Hot-plug drives
● 1.5 Gbit/s, 3.0 Gbit/s and 6.0 Gbit/s link rates for both SAS an SATA
4.6.2 Controller versions
Name Chip PCIe No. of SAS channels
S26361-D2837-Ax LSI SAS2208 PCIe 2.0
2 ports for Blade internal
HDD Connection
S26361-D2837-Cx LSI SAS2208 PCIe 3.0
2 ports for Blade internal
HDD Connection

Fujitsu D2616 Specifications

General

Brand	Fujitsu
Model	D2616
Category	Controller
Language	English
