104
Modular RAID Controllers
Modular RAID 12Gb/s (SAS3.0)
5.5.4 Installation
This section describes how to install the SAS RAID controller in a server.
V CAUTION!
To safeguard against data loss, remember to back up your data before
you change your system configuration.
CacheVault Flash
Module (ONFI)
interface
80-pin connector
Connects the RAID controller to a
TFM (optional)
Cache write
pending connector
2-pin connector
Connector for an LED mounted on
the system enclosure. The LED
indicates that the data in the cache
has yet to be written to the storage
devices.
SAS MLC1
x4 SAS, ports
0- 3
SFF 8644 Mini SAS HD 4e connector
for SAS IO cable to backplane and
HDDs
SAS MLC2
x4 SAS, ports
4- 7
SFF 8644 Mini SAS HD 4econnector
for SAS IO cable to backplane and
HDDs
Connector Type Description
