78
Modular RAID Controllers
Modular RAID 12Gb/s (SAS3.0)
Connectors
Indicators
5.1.4 Installation
This section describes how to install the SAS RAID controller in a server.
V CAUTION!
To safeguard against data loss, remember to back up your data before
you change your system configuration.
To install the new controller, proceed as follows:
Connector Type Description
SAS MLC1 x4 SAS, ports 0- 3
SFF 8643 Mini SAS HD 4i connector for SAS
IO cable to backplane and HDDs
SAS MLC2 x4 SAS, ports 4- 7
SFF 8643 Mini SAS HD 4i connector for SAS
IO cable to backplane and HDDs
HDD LED
HDD activity
indication LED
6-pin connector
Pin 4 to connect activity LED
FBU 1-6 Connector on TFM to attach FBU
LED Description
L1 (green blinking) Heart Beat
Step 1 Unpack the controller
Unpack the new controller in a static-free environment. Remove
it from the anti-static bag and inspect it for damage.
If the controller appears to be damaged, contact the Fujitsu
support service.
Step 2 Prepare the server
Turn off the server and remove the cover from the chassis.
To Next Page
