Modular RAID Controllers
57
Modular RAID 6Gb/s (SAS2.0)
Connectors
RAID controller indicators
TFM indicators
Connector Type Description
SAS MLC1 x4 SAS, ports 0 - 3
SFF 8087 Mini SAS connector for SAS IO
cable to backplane and HDDs
SAS MLC2 x4 SAS, ports 4 - 7
SFF 8087 Mini SAS connector for SAS IO
cable to backplane and HDDs
HDD LED
HDD activity
indication LED
6-pin connector
Pin 4 to connect activity LED
FBU 1-6 Connector on TFM to attach FBU
LED Description
L1 (HB) Heart Beat
L2 (SE0) Error for Power PC0
L3 (SE1) Error for Power PC1
LED Description
L1 (green) Power available
L2 (blue) TFM / FBU status
L3 (yellow) Cache offload fault
