Fujitsu D3488 - Fit Processor on Heat Sink; Heat Sink Preparation; Processor Positioning

Mainboard D3488 English - 33
1
1
1
1
► Press the processor frame with the processor carefully onto the heat sink.
► The processor frame must lock into place (1).
► Install the heat sink again.
