Fujitsu fi-5220C Instruction Manual

1
Versitec 1- 888 - 722 - 6548 www.versitec.com
FI-4120C/FI-4220C
TABLE OF CONTENTS
I. fi-4120C/fi-4220C Parts Replacement
Parts and Consumable Replacement Cycles
Step One: Replacing the Pad Assembly......................... 3 - 4
Step Two: Replacing the Pick Roller.................................5-7
II. fi-4120C/fi-4220C Cleaning Instructions
Parts and Consumable Cleaning Cycles
Step One: Cleaning the Exterior Surfaces and
Document Support........................................................ 8
Step Two: Cleaning the Automatic
Document Feeder .................................................. 9-10
*For the Fi-4120c & Fi-4220c.
Step Three: Cleaning the Flatbed .............................. 10 -11
*For the Fi-4220c Only.
For inquiries during any of these procedures,
contact the Versitec Customer Support Center
at 1-800-224-3475.

Fujitsu fi-5220C Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	2 sec/page
Scanner type	Flatbed & ADF scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	SCSI, USB 2.0
Bundled software	-FJ TWAIN driver. -Scandall. -Adobe Acrobat. -ISIS Driver. -QuickScan (demo). -Soft IPC (demo). -VRS 4.1 Basic.
Dimensions (WxDxH)	302 x 569 x 229 mm
Power requirements	100-240 VAC
Power consumption (standby)	6 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Weight	8400 g
