6.2 Indications operator panel for errors (Continued from the previous page)
Indication Meaning
Ec Memory malfunction
ED SPC malfunction
EF Background switching mechanism malfunction
E10 ROM malfunction
E11 Fan malfunction
E12 Heater malfunction
E13 (Reserve)
E14 (Reserve)
E15 Extended memory option malfunction * See ATTENTION as below.
E16 Option board malfunction
E18 Sensor malfunction
E19 LSI malfunction
E1A Scanner inside communication malfunction
ATTENTION
When the scanner is in trouble, please check as fllows and refer to "9.1 Additional memory board".
1. Is it the right additional memory board?
2. Is the additional memory board set in place?
3. Isn't the additional memory board broken?
4. Are there two additional boards?
When you encounter any alarm, turn off and on the scanner. If the alarm is still displayed on the Function No. display, contact the dealer
where you purchased the scanner or an authorized FUJITSU scanner service provider.
