10.1 Basic Specifications
No. Items Specification Remarks
1 Operating method Automatic Document Feeder(ADF), Flatbed(FB)
2 Image sensor Color CCD (Charge-coupled device) x 3 Front/Back/Flatbed
3 Light source Incandescent cold cathode fluorescent lamp x6 Front/Back/Flatbed
4 Scanning area
Min. A8 (Portrait) Note *1
Max. A3 or 11x17 Long page scanning : 297x863mm Note *2
5 Paper weight
41 g/m
2
to 203 g/m
2
at ADF scanning
6 Scanning speed (A4, Portrait, 200dpi)
ADF
Simplex 55 ppm
Black&White
Grayscale/Color
Note *3
Duplex 110 ipm
FB 0.9 sec.
7 Capacity of ADF 200 sheets
A4, 80 g/m
2
Note *4
*1 The minimum size for scanning is A8 when using the ADF to scan.When using the Flatbed to scan the scanning range is unlimited.
*2 Long page scanning is enabled in case of ADF scanning.
*3 The scanning speed is the maximum speed of the scanner hardware. Software processing time such as data transfer time is added to the
actual scanning time.
*4 The maximum stacking capacity values according to the document thickness.
*5 The SCSI and USB interfaces cannot be used at the same time.
