1.1 NAMES AND FUNCTIONS OF PARTS (Continued from the previous page)
No. Name Function
7 Operator Panel This panel consists of a Function No. display, four buttons and a LED.
8 ADF Paper Chute For scanning documents with the Flat bed, place the document here..
9 Shipping Lock Used to fix the carrier unit. It is securing the carrier during transportation.
10 ADF buttons Press this button to open the ADF.
11 ADF (Automatic Document Feeder)
It transports a document to the reading position automatically. According to needs, this unit can
be set in three directions by turning and sliding it.
12 Stacker Scanned documents are ejected from the ADF onto this tray. It is possible to change the height.
1 | 2 | 3 | 4
