1.1 NAMES AND FUNCTIONS OF PARTS
No. Name Function
1 Document cover When closed, this cover fixes the document set on the reading position.
2 Document Bed For scanning documents with the Flat bed, place the document here.
3 Document Holding Pad It fixes the document by pressing it onto the document bed.
4 ADF Lock Screws Used to fix the ADF. They are securing the ADF during transportation.
5 Screw Storage Holes Holes in where the ADF Lock Screws are placed after unlocking the ADF.
6 Handle Used to open/close the Document Cover.
