Fujitsu Lifebook E360 - Top and Front Components; Left-Side Panel Components

One
Setting Up Your LifeBook E Series
LifeBook E Series from Fujitsu
7
TOP AND FRONT COMPONENTS
Display Panel Latch
This latch locks and releases the display panel.
When the display panel is released it pops up
slightly to make it easier to open. (Figure 1-7.)
Display Panel
This is a color LCD panel with back lighting for
the display of text and graphics. (Figure 1-7.)
Brightness Control
The brightness control adjusts the overall
intensity of the display panel back lighting.
(Figure 1-7.)
Built-in Microphone
The built-in microphone allows mono audio
input to your notebook. (Figure 1-7.)
Status Indicator Panel
An LCD display of the status of the power state
and source, Suspend mode, battery charge (bat-
tery in either Multi-function Bays), floppy disk
drive activity, hard drive or zip drive activity,
CD-ROM drive activity, PC Card activity,
CapsLock, NumLk and ScrLk. (Figure 1-7.)
Stereo Speakers
The built-in dual speakers output stereo sound
from the notebook. (Figure 1-7)
Suspend/Resume Button
The Suspend/Resume button allows you to sus-
pend notebook activity without turning off the
notebook power, and to return it to an active
state. This feature saves power, and is particu-
larly useful when the notebook is running only
on battery power. (See pages 44-49 for more
information on power management.)
(Figure 1-7.)
Closed Cover Switch
The closed cover switch turns off the LCD back
lighting when the display panel is closed, thus
saving power. This switch also behaves as a
Suspend/Resume button, when the closed
cover switch is set to Suspend/Resume in the
BIOS Setup Utility. (see pages 62-63 for more
information on the BIOS Setup Utility)
(Figure 1-7.)
Keyboard
A full-size keyboard with dedicated Windows
keys for input into the notebook.
(Figure 1-7.)
Pointing Device
The pointing device is a mouse-like cursor
control system with two click buttons.
(Figure 1-7.)
CAUTION
Be sure you know which settings are
active for your Suspend/Resume button
before you use it. Misuse can result in
data loss. (See the Power Savings Menu
in the BIOS Guide, see page 63 for more
information.)
