Getting to Know Your LIFEBOOK
7KLVSLFWXUHLVIRULOOXVWUDWLRQSXUSRVHRQO\DQGPD\ORRNGLႇHUHQWIURPWKHDFWXDOXQLW
Side view of LIFEBOOK
Left view
1. LAN Connector
It allows you to connect to a LAN (local area
network) using an optional LAN cable.r
2. Thunderbolt™ 4 Connector
The Thunderbolt™ 4 connector is for a small
24-pin reversible-plug connector for USB
devices and USB cabling. This connector
has power output of 5V / 3A and charging
input function.
3. HDMI Connector
5E15A3
12
3
4 5
2
4. USB 3.2 (Gen 1) Connector
The USB 3.2 (Gen 1) connector with
anytime charging function allows you to
connect Universal Serial Bus devices and is
backward compatible with USB 2.0 devices.
5. Smartcard Slot (Optional)
7KLVSLFWXUHLVIRULOOXVWUDWLRQSXUSRVHRQO\DQGPD\ORRNGLႇHUHQWIURPWKHDFWXDOXQLW
1. Audio In / Out Jack
2. USB 3.2 (Gen 1) Connector
The USB 3.2 (Gen 1) connector allows
you to connect Universal Serial Bus
devices and backward compatible with
USB 2.0 devices.
3. MicroSD card slot
4. Kensington Lock Slot
It allows you to attach an optional physical
lock to lock down the device.
5E14A3
1 3 4
2
To Next Page
