Operation
Operation
Switching the device on and off
1 2 3
1
2 3
1 = On/Off touch sensor
2 = Power indic
ator
3 = 0 W switch (on the rear of the monitor)
The colour of the LED indica tor changes as follows:
LED indicator Status
blue
Monitor and computer are switched on (normal mode).
green
Monitor and computer are switched on (ECO mode).
orange
Monitor is not re ceiving a video signal or is in BASIC power saving
mode.
does not light up
Monitor is switched off (or is in
0 W e nergy-saving mode).
The switch position "0" of the 0 W switch (3) on the rear activates E CO
energy saving mode (0 W operating mode), and switch position "I" switches
to BASIC energy saving mode <1 W. This position is required only for the
DP data cable, but can also be necessary for VGA or DVI on some PCs if
the monitor remains dark in 0 W operating mode.
► Switch the device on with the On/Off touch s ensor (1).
18 Fujitsu
