Fujitsu plasmavision User Manual

E-12
SPECIFICATION
WIDE PLASMA DISPLAY
Regulation
• UL, CSA Safety: UL6500, C-UL
EMC: FCC Part 15 Class B, ICES-003 Class B
• CE Safety: EN60065
EMC: EN55022 1998, Class B
EN61000-3-2 1995
EN61000-3-3 1995
EN55024 1998
EN61000-4-2 1995
EN61000-4-3 1996
EN61000-4-4 1995
EN61000-4-5 1995
EN61000-4-6 1996
EN61000-4-8 1993
EN61000-4-11 1994
• AS Safety: IEC60065
EMC: AS/NZS 3548
Model P42VHA40W/A P42HHA40W/A P50XHA40W/A P55XHA40W/A P63XHA40W/A
Screen size
42" wide screen:
92.1 cm (W) x 51.8
cm (H)
(105.7 cm diagonal)
36.3 inch (W) x 20.4
inch (H)
(41.6 inch diagonal)
42" wide screen:
92.2 cm (W) x 52.2
cm (H)
(106.0 cm diagonal)
36.3 inch (W) x 20.6
inch (H)
(41.7 inch diagonal)
50" wide screen:
110.6 cm (W) x 62.2
cm (H)
(126.9 cm diagonal)
43.5 inch (W) x 24.5
inch (H)
(50 inch diagonal)
55" wide screen:
122.9 cm (W) x 69.1
cm (H)
(140.0 cm diagonal)
48.4 inch (W) x 27.2
inch (H)
(55.1 inch diagonal)
63" wide screen:
139.3 cm (W) x 78.3
cm (H)
(159.8 cm diagonal)
54.8 inch (W) x 30.8
inch (H)
(62.9 inch diagonal)
Aspect ratio 16:9 (wide)
Number of pixels 852 (H) x 480 (V) 1024 (H) x 1024 (V) 1366 (H) x 768 (V)
Weight 31.5 kg / 69 lbs 45 kg / 99 lbs 55 kg / 121 lbs 72 kg / 159 lbs
Outer dimensions 103.9 (W) x 64.0 (H) x 8.7 (D) cm
40.9 (W) x 25.2 (H) x 3.4 (D) inch
(does not include outer projections)
121.6 (W) x 72.6 (H)
x 10.0 (D) cm
47.9 (W) x 28.6 (H)
x 3.9 (D) inch
(does not include
outer projections)
138.0 (W) x 80.8 (H)
x 12.5 (D) cm
54.3 (W) x 31.8 (H)
x 4.9 (D) inch
(does not include
outer projections)
150.4 (W) x 89.4 (H)
x 12.3 (D) cm
59.2 (W) x 35.2 (H)
x 4.8 (D) inch
(does not include
outer projections)
Power supply 110-240 VAC 50/60 Hz
Current rating 3.2-1.35 A 4.2-1.8 A 4.4-1.9 A 5.8-2.3 A 6.8-2.6 A
External equipment terminals
Video input
terminals
VIDEO1 INPUT (Video input) RCA terminal 1 Vp-p/75 Ω
VIDEO2 INPUT (S-video input) S terminal Y: 1 Vp-p/75 Ω
C: 0.286 Vp-p/75 Ω
VIDEO3/VIDEO4 INPUT 3 RCA terminals Y: 1 Vp-p/75 Ω
(Component video input) P
B/CB: 0.7 Vp-p/75 Ω
PR/CR: 0.7 Vp-p/75 Ω
PC input terminal RGB1 input DVI-D terminal (EIA/CEA-861B Compliant)
RGB2 input mD-sub, 3 rows, 15-pin
Picture signal: 0.7 Vp-p/75 Ω
Synchronization signal:TTL level
Audio terminals 2 audio input pin jacks (L/R) (3 lines)
500 mVrms/at least 22 kΩ
Control terminal RS-232C connector (D-sub 9-pin)
External speaker
output terminal
Max. output: 10 W + 10 W, 6 Ω
Operating
conditions
Temperature: 0 to 40 °C / 32 to 104 °F
Humidity: 20 to 80 %
Accessories
3 user's manuals, 1 power cable, 2 small ferrite cores, 2 big ferrite cores, 1 remote control, 2 AA batteries, 1 residential
warranty (for the A model)
