E-6

PART NAMES AND FUNCTIONS (Continued)

 RGB2 input terminal (RGB2 INPUT/mD-sub) for the W/U/A models /

RGB1 input terminal (RGB1 INPUT/mD-sub) for the R model

Connect this terminal to the PC’s display (analog RGB) output terminal or decoder (digital broadcast tuner, etc.) output terminal.

 Component video input terminal (VIDEO3 INPUT)

 Component video input terminal (VIDEO4 INPUT)

Connect this terminal to the component video output (color difference output) terminal of your HDTV unit or DVD player.

 Video input terminal (VIDEO1 INPUT)

Connect this terminal to the video output terminal of your VCR.

When connecting a cable, attach a ferrite core to the cable. (See P. E-2.)

 S-Video input terminal (VIDEO2 INPUT)

Connect this terminal to the S-video output terminal of your VCR.

 Audio3 input terminal (AUDIO3 INPUT)

 Audio2 input terminal (AUDIO2 INPUT)

 Audio1 input terminal (AUDIO1 INPUT)

Connect this terminal to the audio output terminal of your VCR, etc. (See the User’s manual (2/2) for the selection of audio input for video

input.)

 External speaker output terminal (EXT SP)

Connect this terminal to the optionally available speaker.

When connecting a cable, attach a ferrite core to the cable. (See P. E-2.)

* See the speaker instruction manual for more information.

 Power input terminal

Connect this terminal to the power cable supplied with the display.

When connecting a cable, attach a ferrite core to the cable. (See P. E-2.)
