Fujitsu PRIMERGY RX2530 M2 User Manual

Upgrade and Maintenance Manual RX2530 M1
Contents
6.3 Removing a power supply unit . . . . . . . . . . . . . . . . 109
6.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 111
6.3.2 Removing a power supply unit . . . . . . . . . . . . . . . . . 111
6.3.3 Installing the dummy cover . . . . . . . . . . . . . . . . . . . 112
6.4 Replacing a power supply unit . . . . . . . . . . . . . . . . 113
6.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 114
6.4.2 Removing the defective power supply unit . . . . . . . . . . . 114
6.4.3 Installing the new power supply unit . . . . . . . . . . . . . . 114
6.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 114
7 Hard disk drives / solid state drives . . . . . . . . . . . . . 115
7.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 116
7.2 2.5-inch HDD/SSD configurations . . . . . . . . . . . . . . 117
7.2.1 Equipping the 2.5-inch HDD/SSD bays . . . . . . . . . . . . . 117
7.2.2 Configuration with up to four HDD/SSD modules . . . . . . . . 117
7.2.3 Configuration with up to eight HDD/SSD modules . . . . . . . 118
7.2.4 Configuration with up to 10 HDD/SSD modules . . . . . . . . 120
7.2.5 Installing 2.5-inch HDD/SSD modules . . . . . . . . . . . . . 123
7.2.5.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 123
7.2.5.2 Removing a 2.5-inch HDD/SSD dummy module . . . . . . 123
7.2.5.3 Installing a 2.5-inch HDD/SSD module . . . . . . . . . . . 124
7.2.5.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 125
7.2.6 Removing 2.5-inch HDD/SSD modules . . . . . . . . . . . . . 126
7.2.6.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 126
7.2.6.2 Removing a 2.5-inch HDD/SSD module . . . . . . . . . . 127
7.2.6.3 Installing a 2.5-inch HDD/SSD dummy module . . . . . . . 127
7.2.6.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 127
7.2.7 Replacing a 2.5-inch HDD/SSD module . . . . . . . . . . . . 128
7.2.7.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 128
7.2.7.2 Removing the defective 2.5-inch HDD/SSD module . . . . 128
7.2.7.3 Installing the new 2.5-inch HDD/SSD module . . . . . . . . 129
7.2.7.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 129
7.2.8 Replacing the 4 x 2.5-inch HDD backplane . . . . . . . . . . . 129
7.2.8.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 129
7.2.8.2 Removing the defective 4 x 2.5-inch HDD backplane . . . . 130
7.2.8.3 Installing the new 4 x 2.5-inch HDD backplane . . . . . . . 133
7.2.8.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 135

Fujitsu PRIMERGY RX2530 M2 Specifications

General

Processor series	Intel Xeon E5-2600 v4
Processor socket	-
Intel Xeon series	E5-2600
Built-in processor	No
Motherboard chipset	Intel® C612
Compatible processor series	Intel® Xeon® E5 Family
Number of processors supported	2
ECC	Yes
Number of DIMM slots	24
Supported memory types	DDR4-SDRAM
Maximum internal memory	3072 GB
Storage drive sizes supported	3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
PCI Express slots version	3.0
Chassis type	Rack (1U)
Product color	Black
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	770.7 mm
Width	483 mm
Height	43 mm
Weight	16000 g
