Fujitsu PRIMERGY RX2530 M2 User Manual

RX2530 M1 Upgrade and Maintenance Manual 151
Hard disk drives / solid state drives
7.3.4.2 Removing the defective 3.5-inch HDD module
Ê Remove the HDD module as described in section "Removing a 3.5-inch
HDD module" on page 149.
7.3.4.3 Installing the new 3.5-inch HDD module
Ê Install the HDD module as described in section "Installing a 3.5-inch HDD
module" on page 147.
7.3.4.4 Concluding steps
Ê "Performing a RAID array rebuild" on page 96
7.3.5 Replacing the 3.5-inch HDD backplane
7.3.5.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
Ê Release all HDD modules and pull them out a few centimeters, see section
"Removing a 3.5-inch HDD module" on page 149
I The HDD modules need not to be removed completely. But if you
want to remove them nevertheless, check if all HDD modules are
uniquely identified so that you can reinsert them into their original
bays.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less

Fujitsu PRIMERGY RX2530 M2 Specifications

General

Processor series	Intel Xeon E5-2600 v4
Processor socket	-
Intel Xeon series	E5-2600
Built-in processor	No
Motherboard chipset	Intel® C612
Compatible processor series	Intel® Xeon® E5 Family
Number of processors supported	2
ECC	Yes
Number of DIMM slots	24
Supported memory types	DDR4-SDRAM
Maximum internal memory	3072 GB
Storage drive sizes supported	3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
PCI Express slots version	3.0
Chassis type	Rack (1U)
Product color	Black
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	770.7 mm
Width	483 mm
Height	43 mm
Weight	16000 g
