Fujitsu PRIMERGY RX2530 M2 User Manual

Upgrade and Maintenance Manual RX2530 M1
Contents
8 Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
8.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 155
8.1.1 Numbering of the fan modules . . . . . . . . . . . . . . . . . 156
8.2 Replacing a defective fan module . . . . . . . . . . . . . . 158
8.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 158
8.2.2 Removing the defective fan module . . . . . . . . . . . . . . 158
8.2.3 Installing the new fan module . . . . . . . . . . . . . . . . . . 159
8.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 160
9 Expansion cards and backup units . . . . . . . . . . . . . 161
9.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 162
9.1.1 Equipping the PCIe slots . . . . . . . . . . . . . . . . . . . . 162
9.1.2 Equipping the slot for DynamicLoM modules . . . . . . . . . . 165
9.1.2.1 PLAN EM 2x 1GB T . . . . . . . . . . . . . . . . . . . . . 166
9.1.2.2 PLAN EM 4x 1GB T . . . . . . . . . . . . . . . . . . . . . 167
9.1.2.3 PLAN EM 2x 10 GB SFP . . . . . . . . . . . . . . . . . . 168
9.1.2.4 PLAN EM 2x 10 GB T . . . . . . . . . . . . . . . . . . . . 169
9.2 Handling slot brackets . . . . . . . . . . . . . . . . . . . . 170
9.2.1 Installing a slot bracket . . . . . . . . . . . . . . . . . . . . . 170
9.2.2 Removing a slot bracket . . . . . . . . . . . . . . . . . . . . 172
9.2.2.1 Removing the slot bracket . . . . . . . . . . . . . . . . . . 172
9.3 Handling SFP+ transceiver modules . . . . . . . . . . . . . 173
9.3.1 Installing SFP+ transceiver modules . . . . . . . . . . . . . . 173
9.3.2 Removing an SFP+ transceiver module . . . . . . . . . . . . 176
9.4 DynamicLoM modules . . . . . . . . . . . . . . . . . . . . 179
9.4.1 Installing a DynamicLoM module . . . . . . . . . . . . . . . . 179
9.4.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 179
9.4.1.2 Removing the dummy cover . . . . . . . . . . . . . . . . 179
9.4.1.3 Installing the DynamicLoM module . . . . . . . . . . . . . 180
9.4.1.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 182
9.4.2 Removing the DynamicLoM module . . . . . . . . . . . . . . 184
9.4.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 184
9.4.2.2 Removing the DynamicLoM module . . . . . . . . . . . . 184
9.4.2.3 Installing the dummy cover . . . . . . . . . . . . . . . . . 185
9.4.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 185
9.4.3 Replacing the DynamicLoM module . . . . . . . . . . . . . . 186
9.4.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 186

Fujitsu PRIMERGY RX2530 M2 Specifications

General

Processor series	Intel Xeon E5-2600 v4
Processor socket	-
Intel Xeon series	E5-2600
Built-in processor	No
Motherboard chipset	Intel® C612
Compatible processor series	Intel® Xeon® E5 Family
Number of processors supported	2
ECC	Yes
Number of DIMM slots	24
Supported memory types	DDR4-SDRAM
Maximum internal memory	3072 GB
Storage drive sizes supported	3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
PCI Express slots version	3.0
Chassis type	Rack (1U)
Product color	Black
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	770.7 mm
Width	483 mm
Height	43 mm
Weight	16000 g
