98 Operating Manual RX2530 M5
Interfaces
USB connectors USB 3.0 connectors: 4 (2x front, 2x rear)
USB connectors
(10 HDD variant)
USB 2.0 connectors: 1 (1x on front panel QRL)
USB 3.0 connectors: 2 (2x rear)
Graphics (15-pin) 1x VGA (rear)
1x front VGA as an option (not for 10 HDD variant)
Serial (9-pin) 1 x serial RS-232-C, usable for iRMC S5 or system or
shared
LAN / Ethernet OCP option:
–4x 1 Gb
– 2x 10 Gb
– 2x 10 Gb SFP+
– 4x 10 Gb SFP+
– XXV710-DA2 2x 25G/10G
– MCX4-LX 2x 25G/10G
Management LAN
(RJ45)
1 x dedicated management LAN connector for iRMC S5
(10/100/1000 Mbit/s). Management LAN traffic can be
switched to shared onboard Gbit LAN port.
