RX2530 M5 Operating Manual 99
Technical data
Onboard or integrated controllers
RAID controllers PSAS CP400i with "Integrated RAID" (IR)
RAID levels 0 and 1 are supported for internal HDD
configurations.
PRAID EP4x0 (based on LSI SAS3108) SAS/SATA
HDD/SSD up to 12 Gbit/s SAS, 6 Gbit/s SATA, 8 ports
internal/external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
1/2/4 GB cache, optional FBU
PRAID EP520i (based on LSI SAS3508)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 8 ports internal
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
2 GB cache, optional FBU
PRAID EP5x0 (based on LSI SAS3516)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 16 ports internal / 8 ports
external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
4/8 GB cache, optional FBU
SATA controller 1x SATA controller integrated on the system board; up
to eight SATA HDDs/SSDs can be connected to the
controller. The LSI Embedded MegaRAID software
(Software RAID) supports RAID levels 0, 1, 10.
1x single SATA connector for ODD
2x M.2 connector with support for SATA and PCIe
LAN controller OCP onboard;
PXE-Boot via LAN from PXE server, iSCSI / FCoE boot
(also diskless).
Remote
Management
Controller
Integrated Remote Management Controller with
integrated video engine (iRMC S5), 512 MB DDR3
DRAM, IPMI 2.0 compatible.
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 or TCG 2.0
compliant (option)
