Fujitsu PRIMERGY RX600 S6 - Rear Panel Controls and Indicators

RX600 S6 Operating Manual 63
Starting up and operation
5.1.2 Rear of server
5.1.2.1 Global Error indicator and CSS indicator
Figure 10: Global Error indicator and CSS indicator
1 CSS indicator (yellow)
– Lights up yellow if a prefailure event was detected for a CSS
component that you can fix yourself (for reasons of precaution) with
the CSS concept.
– Flashes yellow if an error was detected that you can fix yourself with
the CSS concept.
– Does not light up when the system is OK.
If the event is still acute after a power failure, the indicator is activated
after the restart.
The indicator also lights up in standby mode.
For more information on the CSS concept, see "Hot-plug HDD/SSD
modules" on page 94.
