Fujitsu PRIMERGY TX150 S7 - Mounting the Anti-Tilt Bracket

44 Operating Manual TX150 S7
Setting up the floorstand model Hardware installation
4.2.1 Mounting the anti-tilt bracket
I For safety reasons (risk of tipping), the anti-tilt bracket must be fitted on
the rear of the server on floorstand models with hot-plug power supply
units.
Figure 2: Mounting the anti-tilt bracket
Ê Place the server on the anti-tilt bracket.
Ê Fasten the anti-tilt bracket using the two knurled screws (1).
