2
Figure1-1showsanoutwardappearanceofthiscard.
Figure1-1Outwardappearance
Notes
・ Sincethiscardsupportsthe68-pinconnectorfortheexternalSCSI
deviceonly,don'tusetheotherSCSIconnectorsforconnectingany
SCSIdevice.
・ LeaveboththejumpersJ2andJ4ofthiscardintheirrespectivedefault
settings(short-circuited)withoutfail.
JumperJ2,
JumperJ4
68-pinconnector
forbuilt-inSCSI
device
50-pinconnector
forbuilt-inSCSI
device
68-pinconnectorfor
externalSCSIdevice
LEDconnector
HostadapterLED
AIC-7880SCSIprotocolchip
