3.3ThisCardConfiguration(SCSISelectUtility)
ThiscardcontainstheSCSISelectutilityinthiscard'smemory.Thisutilitycan
changethiscardsettingswithoutremovingtheSERVERcoverorphysicallysetting
theboard.SCSISelectutilitycontainsaSCSIdiskutilitiesthatcanperformlow-level
formattingandcheckthediskmediuminaSCSIharddiskdrive.
(1) Configure/ViewHostAdapterSettings
■ Defaultsettings
Thiscarddefaultsettingsarelistedinthetablebelow.Ifyoudonotneedtochange
thesedefaultsettings,thereisnoneedtoexecuteSCSISelectutility.
Formoreinformationonsettings,refertothedescriptionforeachsettinggivenlater
inthisguide.
SCSIBusInterfaceDifinitions Defaultsetting
HostAdapterSCSIID 7
SCSIParityChecking Enabled
HostAdapterSCSITermination*
4
Automatic
BootDeviceConfiguration Defaultsetting
BootTargetID 0
BootLUNNumber*
1
0
SCSIDeviceConfiguration(#0to#15) Defaultsetting
InitiateSyncNegotiation yes
MaximumSyncTransferRate*
3
40.0
EnableDisconnection yes
InitiateWideNegotiation*
3
yes
SendStartUnitCommand*
2
yes
(Becarefulnotto
changethedefault
setting.)
IncludeinBIOSScan*
2
yes
*1 ThesettingisavailableonlywhentheMultipleLUNSupportisenabled.
*2 EnabledonlywhenHostAdapterBIOSisenabled
*3 Whenthe"SupportforUltraSCSISpeed"issetto｢Enabled｣andthe"InitiateWideNegotiation"issetto｢yes｣,thesetting
valueofthe"MaximumSyncTransferRate"is40MB/s.
*4 TheSCSIterminatorsofthiscardarealwaysactivatedbecausethejumpersJ2andJ4ofthiscardareshort-circuited.
