Fujitsu SCANSNAP iX1400 User Manual

Extension
Stacker
Example: iX1600
3. Attach the Receipt Guide.
For details, refer to "Attaching the Receipt Guide (iX1600 / iX1500 / iX1400)" (page 111).
4. Load documents in the ADF paper chute (cover).
Load documents in the guides on the Receipt Guide according to the width of each guide.
Load the documents face-down and top-first with their back facing you.
Example: iX1600
5. Start scanning.
For iX1600/iX1500, press the [Scan] button in the home screen on the touch panel.
For iX1400, press the [Scan] button on the ScanSnap.
ATTENTION
Do not perform the following operations during scanning. Doing so will stop scanning.
l Connect or disconnect the ScanSnap and other USB devices.
l Close the ADF paper chute (cover).
l Change user accounts on the computer
l Allow the computer to enter sleep mode.
Scanning Documents with iX1600 / iX1500 / iX1400
200

Fujitsu SCANSNAP iX1400 Specifications

General

Scanner type	ADF scanner
Product color	Black
Built-in display	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
Minimum scan area (Flatbed)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS
Certification	CE, RoHS
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3200 g
