Specifications for iX500
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product name ScanSnap iX500
Scanning method Automatic Document Feeder (ADF), simultaneous duplex scanning
Scanning color mode Simplex/duplex, color/gray/black and white/auto (automatic color,
gray, and B&W detection)
Optical system/image sensor Equal-magnification optics/color CIS × 2 (front × 1, back × 1)
Light source 3 color LED (Red/Green/Blue)
Scanning speed (A4 portrait)
Automatic resolution/normal/better/best
25 sheets/minute
Excellent
7 sheets/minute
Scan area Refer to "Documents to Scan (iX500)" (page 212)
Document thickness
Number of sheets allowed to be loaded Up to 50 sheets
A4: 80 g/m
2
(20 lb)
Interface USB USB 3.0 (*1)/USB 2.0/USB 1.1 (connector: B type)
Wireless LAN (*2) IEEE802.11b/g/n compliant
Input power Voltage 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz
Power consumption USB connection During operation: 20 W or less
During sleep mode: 1.6 W or less
Wireless LAN
connection
During operation: 20 W or less
During sleep mode: 2.5 W or less
Temperature/humidity
allowable ranges
Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140 degrees
F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) Min.: 292 × 159 × 168 mm/11.50 × 6.26 × 6.61 in. (when the ADF
paper chute (cover) is closed)
Max.: 292 × 484 × 293 mm/11.50 × 19.06 × 11.54 in. (when the ADF
paper chute (cover) is open and the extension is extended)
Weight 3.0 kg (approx. 6.62 lb)
Environmental specification Compliant with the International Energy Star Program, and RoHS
Directive
Specifications of the ScanSnap
504

Fujitsu SCANSNAP iX1400 Specifications

General

Scanner type	ADF scanner
Product color	Black
Built-in display	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
Minimum scan area (Flatbed)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS
Certification	CE, RoHS
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3200 g
