Fujitsu SCANSNAP iX1400 User Manual

4. Open the ADF paper chute (cover) of the ScanSnap.
ADF Paper Chute (Cover)
a The [Scan] button flashes in blue. The button returns to being lit normally when document
scanning is enabled.
In addition, the ScanSnap Manager icon in the notification area located at the far right of
the taskbar changes from
to .
5. Pull out the extension.
Extension
6. Load the documents in the ADF paper chute (cover).
Load the document face-down and head-first with the back facing you (when loading multiple
documents, the last page is on the top). Adjust the number of documents so that they do not
go beyond the reference marks and are kept within the side guides when they are loaded.
Scanning Documents with S1300i
302

Fujitsu SCANSNAP iX1400 Specifications

General

Scanner type	ADF scanner
Product color	Black
Built-in display	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
Minimum scan area (Flatbed)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS
Certification	CE, RoHS
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3200 g
